RCBO SVL1E-63

Thông số kỹ thuật:

Electrical Features
Mode	Electronic
Type	A
Rated Current In	16, 20, 25, 32, 40, 50, 63A
Poles	2P(1P+N), 4P(3P+N)
Rated Voltage Ue	2P 240V~, 4P 415V~
Insulation Voltage Ui	500V
Rated Frequency	50/60Hz
Rated Residual Operation Current (I△n)	30mA
Rated Residual Operating Current (I△dc)	6mA
Rated Breaking Capacity	10000A
Break Time Under I△n	≤0.1s
Rated Impulse Withstand Voltage (1.5/50) Uimp	4000V
Dielectric Test Voltage at ind.Freq. for 1min	2kV
Pollution Degree	2
Thermo-magnetic Release Characteristic	B, C
Electrical Life	4000 Cycles
Mechanical Life	10000 Cycles

Cài đặt
Contact Position Indicator	Yes
Protection Degree	IP20
Reference Temperature for Setting of thermal element	30℃
Ambient Temperature (with daily average≤35℃)	-25℃~+40℃
Storage Temperature	-25℃~+70℃
Terminal Connection Type	Cable/Pin-type Busbar/U-type Busbar
Terminal Size top/bottom for Cable	25mm² 18~3AWG
Terminal Size top/bottom for Busbar	25mm² 18~3AWG
Tightening Torque	2.5Nm 22In-lbs
Mounting	On DIN Rail EN60715(35mm) by means of fast clip device
Connection	From top

Tripping Current Range:

Circuit Diagram Overall and Installation Dimension (mm)

RCBO NDB1LE-63 C63 Loại A
2024年4月8日 1258
The NDB1LE-63 series of residual current action circuit breakers provide the ground leakage, direct or indirect electric shock by human body and other faults protection, which are applicable to the low -voltage terminal distribution in the industr...
Xem chi tiết
Tiêu chuẩn IEC 60947-2, UL 489 – NDB2T-63 3P
2024年3月13日 1265
NDB2T-63 (UL489) được thiết kế dành riêng cho hệ thống phân phối điện áp thấp trong các lĩnh vực công nghiệp, tòa nhà, năng lượng, viễn thông và hạ tầng.
Xem chi tiết
Bộ ngắt mạch vỏ đúc NDM5-1600H
2023年11月27日 1149
The NDM5-1600 series of moulded case circuit breakers (referred to as circuit breakers) have a rated insulation voltage of 1000V and apply to circuits with the AC 50Hz/60Hz, the rated working voltageAC380/400/415V、AC500V、AC660/690V、AC800V，Va...
Xem chi tiết
RCCB SVL1M-63
2023年8月2日 810
Thông số kỹ thuật: Dải dòng điện ngắt: Kích thước tổng thể và kích thước lắp đặt (mm) Sơ đồ mạch
Xem chi tiết

Lagging Angle	I△n＞0.01A	I△n≤0.01A
0°	0.35I△n ≤ I△ ≤ 1.4I△n	0.35I△n ≤ I△ ≤ 2I△n
90°	0.25I△n ≤ I△ ≤ 1.4I△n	0.25I△n ≤ I△ ≤ 2I△n
135°	0.11I△n ≤ I△ ≤ 1.4I△n	0.11I△n ≤ I△ ≤ 2I△n

Alternative Current Sensitive	Pulsating Direct Current Sensitive	Surge Current Proof
B Class Tripping is ensured for sinusoidal AC residual currents pulsed DC residual current, alternating residual sinusoidal currents up to 1000Hz, pulsating direct residual currents and for smooth direct residual currents, whether applied suddenly or increasing slowly.	They react to AC and pulsating DC fault current which reach 0 or almost 0 within one time period of the mains frequency.	RCCB’s surge capacity. Not tripping at standardized 8/20 us surge-current waves acc.to VDE 0432 Part 2 with surge current values of up to 250A.
