RCCB SVL1M-63

Thông số kỹ thuật:

Tripping Current Range:

Overall and Installation Dimension (mm)

Circuit Diagram

NDG2-200 4P Isolating Switch
2023年5月26日 1266
Applications: NDG2-200/4 Switch Disconnector is applicable to the low-voltage distribution or motor network under AC 50Hz, rated working voltage of AC400V and AC690V and rated working current of 200A for disconnection of infrequent co...
Xem chi tiết
Circuit Breaker for Equipment, Oil damping product NDB3-50 J4 2P, Industrial Automatic Control
2023年9月26日 1371
NDB3-50 is a hydraulic-magnetic circuit breaker for equipment, designed to protect AC and DC control circuits against overload and short circuit. Its modular options support a wide range of equipment and installation requirements. Typical configu...
Xem chi tiết
NDGR3A-250 Isolating Switch
2023年5月26日 1223
Applications: NDG3A－250 disconnecting switches are applicable to the AC/DC power system and mainly installed in the low-voltage distribution circuit. The products can be used for infrequent making and breaking as well as to isolate a...
Xem chi tiết
NDM2E-400(M,H)
2023年5月29日 1014
1. Applicable Scope and Purpose of Circuit Breaker The NDM2E-400 series of electronic molded case circuit breakers (hereinafter referred to as circuit breakers) apply to infrequent switching of circuits with the AC 50Hz, the working voltage of A...
Xem chi tiết

Electrical Features
Mode	Electromagnetic
Type (wave form of the earth leakage sensed)	B
Rated Current In	25, 40, 63A
Poles	2P, 4P
Rated Voltage Ue	2P 240V~, 4P 415V~
Insulation Voltage Ui	500V
Rated Frequency	50/60Hz
Rated Residual Operation Current (I△n)	30mA
Rated Residual Operating Current (I△dc)	6mA
Rated Residual Making & Breaking Capacity (I△m)	500A (In≤40A), 10In (In＞40A)
Short-circuit Current Inc = I△c	10000A
SCPD Fuse
Break Time Under I△n	≤0.1s
Rated Impulse Withstand Voltage (1.5/50) Uimp	4000V
Dielectric Test Voltage at ind.Freq. for 1min	2.5kV
Electrical Life	2000 Cycles
Mechanical Life	4000 Cycles

Cài đặt
Contact Position Indicator	Yes
Protection Degree	IP20
Ambient Temperature (with daily average≤35℃)	-25℃~+35℃
Storage Temperature	-25℃~+70℃
Terminal Connection Type	Cable/Pin-type Busbar/U-type Busbar
Terminal Size top/bottom for Cable	35mm² 18~3AWG
Terminal Size top/bottom for Busbar	35mm² 18~3AWG
Tightening Torque	2.5Nm 22In-lbs
Mounting	On DIN Rail EN60715(35mm) by means of fast clip device
Connection	Power Supply in Both Directions

Lagging Angle	I△n＞0.01A	I△n≤0.01A
0°	0.35I△n ≤ I△ ≤ 1.4I△n	0.35I△n ≤ I△ ≤ 2I△n
90°	0.25I△n ≤ I△ ≤ 1.4I△n	0.25I△n ≤ I△ ≤ 2I△n
135°	0.11I△n ≤ I△ ≤ 1.4I△n	0.11I△n ≤ I△ ≤ 2I△n

Alternative Current Sensitive	Pulsating Direct Current Sensitive	Surge Current Proof
B Class Tripping is ensured for sinusoidal AC residual currents pulsed DC residual current, alternating residual sinusoidal currents up to 1000Hz, pulsating direct residual currents and for smooth direct residual currents, whether applied suddenly or increasing slowly.	They react to AC and pulsating DC fault current which reach 0 or almost 0 within one time period of the mains frequency.	RCCB’s surge capacity. Not tripping at standardized 8/20 us surge-current waves acc.to VDE 0432 Part 2 with surge current values of up to 250A.
